TYPE 3109

TRAPEZOIDAL SEGMENTS

Trapezoidal segments TYPE 3109 are designed for rough and fine grinding of flat surfaces of steel, cast steel, non-ferrous metals, cast iron. They are mostly used in the tool, machine and automotive industries on surface grinding machines with segment heads.

ANDRE TYPE 3109 segments with vitrified bond are manufactured, among others, on the basis of brown aluminium oxide (95A), white aluminium oxide (99A), black silicon carbide (98C) and green silicon carbide (99C). For specialized applications, ANDRE also offers other combinations of abrasive grains with excellent performance characteristics.

3109 - B / A x C x L

Example of labeling:
3109 -100/85x35x150-99A36J7VE01

Download

DIMENSION TABLE
PRODUCT EXAMPLES

Parameters of the offered abrasive tools of the presented type

TYPE 3109
Dimensions [mm]
B	A	C	L
60	47	21	120
61	55	20	165
70	64	25	110
70	64	25	150
81	87	40	160
100	85	35	150
	85	35	200
	85	40	150
101	77	45	203
103	94	38	150
119	105	41	250
125	115	40	250

*) Other parameters available according to individual arrangements.

Examples of manufactured abrasive tools of the presented type

For rough and finish grinding of flat surfaces of steel, cast steel, non-ferrous metals, hard cast iron, carbide and plastics.

99A
Code	Dimensions [mm]	Characteristics	Speed [m/s]	In a box
540252	100/85 × 35 × 150	99A36J7VE01	-	16
